MOS 6561 VIC (PAL)

We're preparing and photographing a MOS 6561 VIC chip.

The first surface image was produced 3/1/2011.

1600 x 1622 PNG 5.7 mb
6500 x 6588 PNG 77.7 mb
The die shot is stitched from many separate microscope shots by Greg James using a Nikon LV150 with an LU Plan Fluor 20x objective. The images were corrected and stitched automatically by Christian Sattler in the UK, using Autopano-sift-C and custom code.

Read about the VIC on Wikipedia.
